KLU-1600 - Eaton Bussmann 1600A 600V Class L Time Delay Fuse, 1 Pole, Bolt Mount, 200kA Interrupt Rating

KLU-1600

KLU-1600 is a Eaton Bussmann Class L time delay fuse rated for 1600 amperes and 600 volts AC, designed for reliable circuit protection.This fuse features a 1-pole configuration with bolted blade end connections and a bolt mounting method. It provides a 5-second time delay at 500% rated current and a high interrupting rating of 200,000 amperes at 600 VAC. The KLU-1600 is non-indicating and part of the Limitron series, compliant with UL 248-10, CSA, and CE certifications. It is RoHS compliant and CE marked for safety and environmental standards.

Key Specifications
• Amperage: 1600 A
• Voltage: 600 VAC
• Poles: 1
• Mounting Type: Bolt
• Interrupt Rating: 200 kAIC at 600 VAC
• Fuse Class: L
• Time Delay: 5 seconds at 500% rated current
• Connection: Bolted blade end x bolted blade end
• Indicating: Non-indicating
• Certifications: UL 248-10, CSA, CE
• Series: Limitron KLU
• RoHS Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KLU-1600
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : LIMITRON
• Type : KLU
• Voltage : 600
• Amperage : 1600
• AIC rating : 200kA@600V
• Connection : Bolt-In
• Diameter : 3
• Class Rating : L
• Barrels : 1

Product Data

• UPC : 051712135092
• GTIN : 00051712135092
• Country of Origin : Mexico
• Dimensions : 3 in x 1.75 in x 3 in (Length/Depth x Height x Width)
• Weight : 5.95
• Certification : CE/UL-248-10 Guide JDDZ/CSA Class 1422-02
