KLKR030 - Littelfuse Class CC Fast Acting Fuse 30A 600V AC 300V DC 1.5 Inch

KLKR030

KLKR030 is a Littelfuse Class CC fast acting fuse designed for reliable branch circuit protection.KLKR030 features a compact 1.5 inch cartridge body made of melamine with nickel-plated bronze end caps. It provides fast-acting, current-limiting protection rated for 30 amps, 600 volts AC, and 300 volts DC. This fuse has a high interrupting rating of 200,000 amps at 600 VAC and 20,000 amps at 300 VDC, ensuring superior protection against short circuits and overloads. The KLKR series includes rejection features to prevent substitution with lower-rated fuses, complying with UL 248-4, CSA, and CE standards.

Key Specifications
• Amperage: 30A
• Voltage Rating: 600V AC, 300V DC
• Fuse Class: CC
• Fuse Type: Fast Acting
• Interrupting Rating: 200 kA at 600 VAC, 20 kA at 300 VDC
• Body Material: Melamine
• Body Style: Cartridge, 1.5 inch length
• End Caps: Nickel-plated bronze
• Mounting Type: Fuse holder
• Certifications: UL 248-4, CSA, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KLKR030
• Manufacturer : Littelfuse
• Brand : Littelfuse
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : KLKR Series - Class CC Dual-Element, Fast-Acting Fuses
• Type : KLKR Series - Class CC Dual-Element, Fast-Acting Fuses
• Voltage : 600
• Amperage : 30
• AIC rating : 200kA@600V
• Connection : Ferrule
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1
• Velocity : TD - Time Delay

Product Data

• UPC : 079458260731
• GTIN : 00079458260731
• Country of Origin : Mexico
• Dimensions : x 1-1/2 in x
• Weight : 0.02
• Certification : CE, CSA Certified, RoHS, UL 248-4, UL Listed
