KLDR03.5 - Littelfuse 3.5 Amp 600V AC Class CC Time-Delay Fuse

KLDR03.5

KLDR03.5 is a Littelfuse Class CC time-delay fuse rated for 3.5 amps and 600 volts AC designed for transformer and solenoid protection.

This fuse features a melamine body with nickel-plated bronze end caps, providing extremely current-limiting protection with a high interrupting rating of 200,000 AIC at 600 VAC and 20,000 AIC at 300 VDC. It meets UL 248-4 and CSA standards and is RoHS compliant. The fuse size is 0.41 inches in diameter by 1.5 inches in length, suitable for use in compatible Class CC fuse blocks with rejection capability to prevent incorrect fuse installation.

• Amperage: 3.5 A
• Voltage Rating: 600 V AC, 300 V DC
• Fuse Type: Time-Delay
• Interrupting Rating: 200,000 AIC AC, 20,000 AIC DC
• Body Material: Melamine
• End Caps: Nickel-plated Bronze
• Standards: UL 248-4, CSA
• RoHS Compliant
• Physical Size: 0.41" diameter x 1.5" length
• Designed for transformer and solenoid protection
• Class CC with rejection capability

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KLDR03.5
• Manufacturer : Littelfuse
• Brand : Littelfuse
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : KLDR Series – Class CC Time-Delay Fuses
• Type : KLDR Series – Class CC Time-Delay Fuses
• Voltage : 600
• Amperage : 3.5
• AIC rating : 200kA@600V
• Connection : Ferrule
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1
• Velocity : TD - Time Delay

Product Data

• UPC : 079458792607
• Country of Origin : Mexico
• Dimensions : x 1-1/2 in x
• Weight : 7
• Certification : CE, UL 248-4, UL Listed, CSA Certified, RoHS
