KLDR-03.5 - Littelfuse 3.5A 600V AC Class CC Time-Delay Fuse

KLDR-03.5

KLDR-03.5 is a Littelfuse Class CC time-delay fuse rated for 3.5 amps and 600 volts AC, designed for reliable protection of control transformers and inductive loads.

This KLDR series fuse features a fast blow time-delay characteristic, high interrupt rating of 200 kA at 600 VAC, and is sized to meet UL 508 and UL 845 standards. It provides excellent protection against short circuits and allows temporary current surges without blowing, making it ideal for motor branch circuits and control power transformers. The fuse body is melamine, compatible with L600C fuse blocks, and offers rejection capability to prevent improper fuse substitution.

Key Specifications
• Amperage: 3.5 A
• Voltage Rating: 600 VAC, 300 VDC
• Interrupt Rating: 200 kA at 600 VAC, 20 kA at 300 VDC
• Fuse Class: Class CC
• Time-Delay (Fast Blow)
• Poles: Single Pole
• Mounting Type: Fuse Holder Compatible (L600C series)
• Body Material: Melamine
• Dimensions: 13/32 in x 1 1/2 in
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KLDR-03.5
• Manufacturer : Littelfuse
• Brand : Littelfuse
• Category : Fuse
• Item Subcategory : Medium Voltage

Product Data

• Weight : 5.19
