KDC2225 - Eaton Series C K-Frame Molded Case Circuit Breaker 225A 600VAC 2-Pole Fixed Thermal Magnetic Trip

KDC2225

KDC2225 is a Series C K-frame molded case circuit breaker designed for reliable electrical protection in commercial and industrial applications. This two-pole breaker features a fixed thermal and fixed magnetic trip unit for consistent overcurrent protection. The KDC2225 is rated for 225A continuous current and 600 Vac, 250 Vdc voltage, with an interrupt rating of 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, and 65 kAIC at 600 Vac. It is constructed with aluminum line and load terminals and is suitable for 50/60 Hz operation. The breaker is UL Listed and designed for standard mounting in compatible electrical enclosures.

• Amperage Rating: 225 A
• Voltage Rating: 600 Vac, 250 Vdc
• Number of Poles: 2
• Interrupt Rating: 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, 65 kAIC at 600 Vac
• Frame Type: K-frame
• Series: Series C
• Mounting Type: Standard
• Terminal Material: Aluminum
• Terminals: Line and load
• Frequency Rating: 50 to 60 Hz
• Trip Type: Fixed thermal, fixed magnetic
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KDC2225
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : KDC
• Voltage : 600
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 100kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679069745
• GTIN : 00786679069745
• Country of Origin : Dominican Republic
• Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11.5
• Certification : UL Listed
