KD2400 - Cutler Hammer 400A 600V 2-Pole Series C K-Frame Molded Case Circuit Breaker

KD2400

KD2400 is a Cutler Hammer Series C K-Frame molded case circuit breaker rated for 400 amps and 600 volts with 2 poles.This circuit breaker features a fixed thermal and fixed magnetic trip unit designed for reliable protection in industrial and commercial electrical systems. It supports feed-thru mounting and offers an interrupt rating of 65 kAIC at 240 VAC and 35 kAIC at 480 VAC. The breaker is UL listed and suitable for 50/60 Hz applications.

• Amperage: 400A
• Voltage: 600 VAC / 250 VDC
• Poles: 2
• Series/Frame: Series C K-Frame
• Interrupt Rating: 65 kAIC at 240 VAC, 35 kAIC at 480 VAC
• Mounting Type: Feed-Thru
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Standards: UL Listed
• Frequency: 50/60 Hz
• Dimensions: Approx. 4.1" H x 5.5" W x 5.5" D
• Weight: Approx. 11.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KD2400
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : KD
• Voltage : 600
• Amperage : 400
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Frame Size : K Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679349090
• GTIN : 00786679349090
• Country of Origin : Dominican Republic
• Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11.5
• Certification : UL Listed
