Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
KBC-500
KBC-500 is a high-capacity cartridge fuse designed for industrial power distribution and circuit protection applications requiring fast-blow response.
The Eaton Bussmann KBC-500 is a semiconductor fuse cartridge rated for 500 amperes at 600VAC with a 200kA RMS symmetrical interrupting rating. This fast-blow fuse features stud-type mounting and is suitable for DC applications up to 1000VDC. The KBC series provides reliable overcurrent protection in demanding electrical systems and is recognized for use in replacement applications. For new installations, Eaton recommends upgrading to the 700V FWP series fuse.
- Current Rating: 500A
- Voltage Rating: 600VAC / 1000VDC
- Interrupting Rating: 200kA RMS Symmetrical
- Fuse Type: Cartridge
- Response Time: Fast Blow
- Mounting Style: Stud
- Series: KBC
- Semiconductor Fuse: Non-Indicating
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: KBC-500
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : KBC Series
- Type : KBC
- Voltage : 600
- Amperage : 500
- AIC rating : 200kA@600V
- Connection : Stud
- Diameter : 2
- Barrels : 1
Product Data
- UPC : 051712495004
- GTIN : 00051712495004
- Country of Origin : Mexico
- Dimensions : 7 in x 2.8 in x 1.91 in (Length/Depth x Height x Width)
- Weight : 1.35
- Certification : UL Recognized,CE Marked
