Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
KAF26125
KAF26125 is a Square D molded case circuit breaker designed for reliable overcurrent protection in commercial and industrial applications.This 2-pole circuit breaker features a 125 ampere trip rating with a 250 ampere frame type, suitable for 600 volt AC systems. It uses a thermal-magnetic trip unit to provide both overload and short circuit protection. The breaker is an I-Line plug-on type, allowing easy installation and replacement. It has an interrupt rating of up to 22kA at 600 VAC and is compatible with wire sizes from 1 AWG to 350 kcmil.
- Key Specifications
- Amperage: 125A trip, 250A frame
- Voltage Rating: 600 VAC
- Poles: 2
- Mounting Type: I-Line plug-on
- Interrupt Rating: 22kA @ 600 VAC, 10kA @ 125 VDC, 10kA @ 250 VDC, 25kA @ 480 VAC, 42kA @ 120 VAC, 42kA @ 240 VAC
- Trip Unit: Thermal-Magnetic
- Wire Range: 1 AWG to 350 kcmil
- Frame Type: 250A
- Part Number: KAF26125
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : KAF Series
- Type : KAF
- Voltage : 600
- Amperage : 125
- Phase : 1
- Poles : 2
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : K Frame
- Protection : Thermal Magnetic
- Weight : 8
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
