KA26250BC - Square D 250A 600V 2-Pole KA Frame I-Line Plug-In Circuit Breaker

KA26250BC

KA26250BC is a Square D 2-pole, 250 amp, 600 volt KA frame molded case circuit breaker designed for I-Line plug-in panelboards.

This circuit breaker features thermal magnetic trip units with long time and instantaneous trip functions. It is UL and CSA approved for power distribution applications with interrupting ratings up to 65kA at 240 VAC and 25kA at 600 VAC. The breaker supports mounting via plug-on type and accepts wire sizes from 6 AWG to 350 kcmil aluminum or copper conductors. It is suitable for use in commercial and industrial environments requiring reliable circuit protection.

• Amperage: 250 A
• Voltage Rating: 600 VAC
• Poles: 2
• Frame Type: KA
• Mounting Type: Plug-On
• Interrupting Rating: Up to 65kA at 240 VAC, 25kA at 600 VAC
• Trip Unit: Thermal Magnetic
• Certifications: UL, CSA
• Wire Size Range: 6 AWG to 350 kcmil (Aluminum/Copper)
• Dimensions: 4.5" W x 4.75" D x 8" H
• Phase: Single Phase
• Application: I-Line Panelboards/Switchboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KA26250BC
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : KA
• Voltage : 600
• Amperage : 250
• Phase : 1
• Poles : 2
• AIC rating : 25kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 13
