JXD22B200 - Siemens 200 Amp 240 Volt 2 Pole Molded Case Circuit Breaker JD Frame

JXD22B200

JXD22B200 - Siemens 2-pole molded case circuit breaker with thermal magnetic trip unit, JD frame, rated at 200A and 240VAC.

This bolt-on circuit breaker provides reliable overcurrent protection for 1-phase systems at 240VAC, featuring a JD frame size and thermal magnetic trip for long-time and instantaneous functions. It supports wire sizes via lug kit TA2J6500 (3/0 AWG to 500 kcmil) with dimensions of 7.5 in. wide x 11 in. high x 5.44 in. deep and weighs 20 lbs.

Key Specifications

• Amperage: 200A
• Voltage: 240VAC (50/60 Hz), 250VDC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA at 240VAC
• Series/Frame: JD/JXD
• Trip Unit: Thermal Magnetic (LI)
• Phase: 1
• Dimensions: 7.5 x 11 x 5.44 in.
• Weight: 20 lbs.

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: JXD22B200
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : JXD
• Voltage : 240
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 65kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 400A/JD
• Temp Rating : -13¡F-158¡F (-25¡C - 70¡C)
• MCM Size : 500 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Not Applicable

Product Data

• UPC : 783643212862
• GTIN : 00783643212862
• Country of Origin : Mexico
• Dimensions : 8.661 x 12.992 x 6.693
• Weight : 15.201
• Panel Type : SB Switchboards Without Lugs, Sentron Panelboards
• Standards : RoHS
• Certification : UL, IEC
