Product Info
- Manufacturer:Littelfuse
- Sub-Category:Low Voltage
Description
JTD6
JTD6 is a Littelfuse Class J time delay fuse rated for 6 amps and 600 volts AC.
This fuse features a dual element design for time delay and current limiting, providing reliable protection with IEC Type 2 "No Damage" classification. It has a physical size of 13/16" diameter by 2 1/4" length, an interrupting rating of 200,000 AIC at 600 VAC, and 20,000 AIC at 300 VDC. The fuse body is melamine with nickel-plated bronze end caps, UL listed (File: E81895) and CSA certified (File: LR29862).
- Key Specifications
- Amperage: 6 A
- Voltage Rating: 600 VAC, 300 VDC
- Fuse Class: Class J
- Time Delay, Dual Element
- Interrupting Rating: 200 kA AC, 20 kA DC
- Physical Size: 13/16" x 2 1/4"
- Mounting Type: Cartridge
- Certifications: UL Listed, CSA Certified
- Material: Melamine body, nickel-plated bronze caps
- IEC Type 2 Protection
- Part Number: JTD6
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : Powr-Pro
- Type : JTD
- Voltage : 600
- Amperage : 6
- AIC rating : 200kA@600V
- Connection : Bolt-In
- Diameter : 0.81
- Class Rating : J
- Barrels : 1
- Weight : 0.08
