Product Info
- Manufacturer:Littelfuse
- Sub-Category:Low Voltage Fuse
Description
JLLS1000
JLLS1000 is a Littelfuse Class T fast-acting fuse rated for 1000 amps and 600 volts AC/300 volts DC, designed for industrial power protection.This fuse features a compact, knife-blade bolt-in mounting design that provides extremely current-limiting protection with a high interrupting rating. It is UL listed and CSA certified, offering reliable interruption of overcurrents up to 200,000 amps AC and 20,000 amps DC. The JLLS1000 is ideal for protecting variable speed drives and other sensitive equipment requiring fast response.
- Fuse Type: Class T
- Amperage Rating: 1000 Amps
- Voltage Rating: 600 VAC / 300 VDC
- Mounting Type: Knife-Blade Bolt-In
- Interrupting Rating: 200,000 AIC at 600 VAC, 20,000 AIC at 300 VDC
- Fast-Acting, Current-Limiting
- Compact Design
- UL Listed, CSA Certified
- Physical Size: 2.63" diameter x 5.27" length
Specifications
- Part Number: JLLS1000
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : JLLS
- Type : JLLS
- Voltage : 600
- Amperage : 1000
- AIC rating : 200kA
- Connection : Bolt-In
- Diameter : 2.63
- Class Rating : T
- Barrels : 1
- Velocity : FA - Fast Action
Product Data
- UPC : 079458010602
- GTIN : 00079458010602
- Weight : 4
