JJS-10 - Eaton Bussmann Class T Fast-Acting Fuse 10A 600V 200kAIC Ferrule End x Ferrule End

JJS-10

JJS-10 is an Eaton Bussmann Class T fast-acting fuse designed for high-performance circuit protection.This 10 amp, 600 volt fuse features a current-limiting design with a 200 kA interrupt rating at 600 VAC, ideal for protecting variable frequency drives and other sensitive equipment. It has a small footprint and ferrule end x ferrule end connection type, providing reliable, non-indicating protection in a compact form.

Key Specifications
• Amperage Rating: 10 A
• Voltage Rating: 600 V AC
• Interrupt Rating: 200 kAIC at 600 VAC
• Fuse Class: Class T
• Fuse Type: Fast-Acting, Current-Limiting
• Connection Type: Ferrule End x Ferrule End
• Physical Size: Small Footprint
• Fuse Indicator: Non-Indicating
• Certifications: CE Marked, RoHS Compliant
• Packaging: Standard
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: JJS-10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : T-Tron
• Type : JJS
• Voltage : 600
• Amperage : 10
• AIC rating : 200kA@600V
• Diameter : 0.56
• Class Rating : T
• Barrels : 1



Product Data

• UPC : 051712628105
• GTIN : 00051712628105
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.035
• Certification : CE/UL-248-15 Guide JDDZ/CSA Class 1422-02
