Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
JJP36250AA
JJP36250AA is a Schneider Electric PowerPact J-Frame molded case circuit breaker rated for 250 Amps and 600 VAC with 3 poles and thermal magnetic trip unit.This circuit breaker features a 25 kA interrupt rating at 600 VAC, unit mount design, and is UL 489 listed. It supports overload and short-circuit protection with lugs for line/load connections. The breaker is suitable for industrial and commercial power distribution applications requiring reliable circuit protection.
- Amperage: 250 Amps
- Voltage Rating: 600 VAC
- Number of Poles: 3
- Interrupt Rating: 25 kA at 600 VAC
- Mounting Type: Unit Mount
- Trip Unit: Thermal Magnetic
- Series/Frame: PowerPact J-Frame
- Certifications: UL 489 Listed, CSA, IEC, NOM, UKCA, CE Marked
- Terminal Type: Lugs for line and load
- Application: Molded Case Circuit Breaker for power distribution
Specifications
- Part Number: JJP36250AA
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
Product Data
- Country of Origin : United States
- Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 5
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
