Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
JJP36200CA
JJP36200CA is a Schneider Electric PowerPact J Frame circuit breaker designed for reliable overcurrent protection in electrical distribution systems.This 200 amp, 3 pole circuit breaker features a thermal-magnetic trip unit and a unit mount design, suitable for switching and protecting AC systems up to 600 volts. It has a breaking capacity of 25kA at 600VAC and supports continuous current rating at 80%. The breaker complies with UL 489, CSA, IEC, CCC, NOM, UKCA, and CE certifications, ensuring high safety and performance standards.
- Amperage: 200A
- Voltage Rating: 600VAC
- Number of Poles: 3
- Mounting Type: Unit Mount
- Interrupt Rating: 25kA at 600VAC
- Trip Unit: Thermal Magnetic
- Series/Frame: PowerPact J Frame
- Certifications: UL 489, CSA, IEC, CCC, NOM, UKCA, CE
Specifications
- Part Number: JJP36200CA
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Temp Rating : 28-122 °F (-2-50 °C)
Product Data
- Country of Origin : United States
- Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 5
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
