JGS3100FAG - Cutler Hammer 100A 600V 3 Pole Molded Case Circuit Breaker, Series G, JG Frame, Fixed Thermal Adjustable Magnetic Trip

JGS3100FAG

JGS3100FAG is a Cutler Hammer Series G molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 3-pole breaker features a JG frame, fixed thermal and adjustable magnetic trip unit, and is rated for 100A at 600V AC and 250V DC. It offers high interrupting capacity and is suitable for use in switchboards, MCCs, and control panels. Engineered for durability and safety, the JGS3100FAG provides long-time and instantaneous (LI) protection with feed-thru connections and a free-standing mounting style. It is UL, CSA, and IEC listed for compliance with major safety standards.

• Part Number: JGS3100FAG
• Manufacturer: Cutler Hammer
• Series: Series G
• Frame Type: JG
• Poles: 3
• Amperage Rating: 100A
• Voltage Rating: 600V AC, 250V DC
• Interrupt Rating: 18 kAIC @ 600V, 35 kAIC @ 480V, 85 kAIC @ 240V
• Mounting Type: Free Standing
• Connection: Feed-Thru
• Protection Type: Thermal Magnetic
• Certifications: UL, CSA, IEC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGS3100FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : JGS
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/JG
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 782113963310
• GTIN : 00782113963310
• Country of Origin : Dominican Republic
• Dimensions : 3.44 in x 7 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 6
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
