JGL36250SA - Schneider Electric 250A 600V 3-Pole PowerPacT J Molded Case Circuit Breaker

JGL36250SA

JGL36250SA is a Schneider Electric PowerPacT J series molded case circuit breaker rated for 250 amps and 600 volts with 3 poles.This thermal magnetic circuit breaker provides reliable overcurrent protection and switching for AC systems. It features a breaking capacity of 18kA at 600VAC, 80% continuous current rating, and lug-type mounting. The breaker is UL 489 listed and meets CSA, NOM, IEC, CCC, UKCA, and CE certifications.

• Amperage: 250A
• Voltage: 600 VAC
• Poles: 3
• Interrupt Rating: 18kA at 600VAC
• Frame/Series: PowerPacT J
• Trip Unit: Thermal Magnetic
• Mounting Type: Lug
• Continuous Current Rating: 80%
• Certifications: UL 489, CSA, NOM, IEC, CCC, UKCA, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGL36250SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Voltage : 600
• Amperage : 250
• Phase : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 7.85902E+11
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
