Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
JGE4250FAG
JGE4250FAG is a 4 pole, 250 amp, 600 volt molded case circuit breaker from the Cutler Hammer Series G line, designed for feed-thru applications with fixed thermal and adjustable magnetic trip units. This breaker features a 65kA interrupt rating at 240V, 25kA at 480V, and 18kA at 600V, making it suitable for a wide range of industrial and commercial power distribution systems. It includes standard line and load terminals and is neutral 0% protected.
- Part Number: JGE4250FAG
- Manufacturer: Cutler Hammer
- Amperage: 250A
- Voltage: 600V
- Poles: 4
- Mounting Type: Feed-Thru
- Interrupt Rating: 65kA @ 240V, 25kA @ 480V, 18kA @ 600V
- Series/Frame: Series G, JG Frame
- Neutral Protection: 0%
- Line/Load Terminals: Standard
- Trip Unit: Fixed Thermal, Adjustable Magnetic
- Certifications: UL Listed
Specifications
- Part Number: JGE4250FAG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : JGE
- Voltage : 600
- Amperage : 250
- Phase : 3
- Poles : 4
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 782113526881
- GTIN : 00782113526881
- Country of Origin : Dominican Republic
- Dimensions : 3.57 in x 5.34 in x 5.34 in (Length/Depth x Height x Width)
- Weight : 8
- Certification : CSA Certified,IEC Rated,UL Listed,CE Marked
