JGE3100AAG - Cutler Hammer 100A 600V 3-Pole Molded Case Circuit Breaker Series G JG-Frame

JGE3100AAG

This 3-pole circuit breaker features a 100 ampere rating and supports voltages up to 600 Vac and 250 Vdc. It belongs to the Eaton Series G with a JG-frame and includes adjustable thermal and magnetic trip units for reliable protection. The breaker offers a 25 kA interrupting rating at 480 V and 65 kA at 240 V, suitable for high fault current environments. It is designed for panel mounting and meets industry certifications for safety and performance.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: JGE3100AAG
• Amperage: 100A
• Voltage: 600 Vac, 250 Vdc
• Poles: 3
• Series/Frame: Series G, JG-frame
• Interrupt Rating: 25 kA at 480 V, 65 kA at 240 V
• Trip Unit: Adjustable thermal and magnetic
• Mounting Type: Panel mount
• Certifications: Industry standard safety certifications (UL, CSA typical for Eaton breakers)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: JGE3100AAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : JGE
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 78211488619
• GTIN : 00782114886199
• Dimensions : 3.44 in x 7 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 6
