JGE3070FAG - Cutler Hammer Series G 70A 600VAC 3-Pole Molded Case Circuit Breaker

JGE3070FAG

JGE3070FAG is an Eaton Series G molded case circuit breaker designed for industrial and commercial power distribution applications. This three-pole breaker features a JG-frame with fixed thermal and adjustable magnetic trip units, providing reliable overcurrent protection and ground fault detection down to 20 amperes. The unit is rated for 70 amperes at 600 VAC or 250 VDC with interrupt ratings of 65 kA at 240 VAC, 25 kA at 480 VAC, and 18 kA at 600 VAC, making it suitable for a wide range of electrical systems. Internal and external accessory combinations are available to customize the breaker for specific installation requirements.

• Amperage Rating: 70A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 3
• Series/Frame: Series G, JG-Frame
• Trip Unit: Fixed Thermal, Adjustable Magnetic
• Interrupt Rating: 65 kA @ 240 VAC, 25 kA @ 480 VAC, 18 kA @ 600 VAC
• Ground Fault Protection: Down to 20 amperes
• Certifications: UL Listed, CSA Certified, IEC Rated
• Compliance: CE Marked

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGE3070FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : JGE
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782113960845
• GTIN : 00782113960845
• Country of Origin : Dominican Republic
• Dimensions : 3.44 in x 7 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 6
• Certification : CSA Certified,UL Listed,IEC Rated,CE Marked
