JGA36225SA - Square D 225A 3-Pole 600V I-Line PowerPact Circuit Breaker

JGA36225SA

JGA36225SA is a 225 amp, 3-pole circuit breaker from Square D's PowerPact family designed for reliable power distribution protection.This molded case circuit breaker features thermal magnetic trip units and is rated for 600 volts AC. It is intended for use in I-Line panelboards and switchboards, providing robust protection with a breaking capacity of up to 18kA at 600VAC. The breaker is UL and CSA approved, ensuring compliance with industry safety standards.

• Amperage: 225A
• Voltage Rating: 600V AC
• Poles: 3
• Mounting Type: I-Line panelboard/switchboard
• Interrupt Rating: 18kA at 600VAC
• Trip Unit: Thermal Magnetic
• Series/Frame: PowerPact J
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 110/130V shunt trip

Specifications

• Part Number: JGA36225SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGA
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : I-Line, Lug
• Frame Size : J
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 3/0 AWG (Cu/Al) Max. Wire Size 350 kcmil (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 78590194717
• GTIN : 00785901947172
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
