JGA36200SA - Square D 200A 600V 3-Pole Thermal Magnetic Circuit Breaker I-Line J Frame

JGA36200SA

JGA36200SA is a 3-pole thermal magnetic molded case circuit breaker from Square D designed for reliable overcurrent protection in industrial and commercial applications.This Square D circuit breaker features a 200 ampere rating, supports voltages up to 600 VAC and 500 VDC, and is built on the J Frame with I-Line mounting style. It offers multiple interrupt ratings including 65 kA at 240 VAC, 35 kA at 480 VAC, and 18 kA at 600 VAC, ensuring high fault current interruption capability. UL 489 listed and certified by CSA, CE, and IEC, it is suitable for panelboards and switchboards requiring robust protection.

Key Specifications
• Amperage: 200 A
• Voltage Rating: 600 VAC, 500 VDC
• Poles: 3
• Frame Type: J Frame
• Mounting Type: I-Line
• Interrupt Ratings: 65 kA @ 240 VAC, 35 kA @ 480 VAC, 18 kA @ 600 VAC
• Trip Unit: Thermal Magnetic
• UL Listing: UL 489
• Certifications: UL, CSA, CE, IEC
• Interrupt Code: G
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: JGA36200SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Type : PowerPacT J
• Voltage : 600VAC, 250VDC
• Amperage : 200
• Phase : 3
• Poles : 3
• AIC rating : 65kAIC at 240VAC, 35kAIC at 480VAC, 18kAIC at 600VAC
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic
• Compatible Frames : JGA



Product Data

• UPC : 785901947165
• GTIN : 785901947165
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
