Product Info
- Manufacturer:Edison Fuses
Description
JDL7
JDL7 is a 7 amp, 600 volt Class J time-delay current-limiting fuse from Edison Fuses designed for reliable circuit protection.This non-indicating dual-element fuse provides a minimum 10-second time-delay at 500% overload, minimizing nuisance openings from temporary surges. It features a high interrupting rating of 200kA RMS symmetrical, suitable for industrial and commercial applications requiring space-saving, high-performance fusing. The fuse complies with UL 248-8, CSA C22.2 No. 248.8, CE, and RoHS standards.
- Key Specifications
- Amperage: 7A
- Voltage Rating: 600 VAC
- Fuse Type: Class J, Dual-Element, Time-Delay
- Interrupt Rating: 200kA RMS Symmetrical
- Dimensions: 1-1/2 inch length, 13/32 inch ferrule diameter
- Mounting Type: Cartridge
- Certifications: UL, CSA, CE, RoHS compliant
- Non-indicating fuse
- Current Limiting
- Suitable for backup motor protection
Specifications
- Part Number: JDL7
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
Product Data
- UPC : 78433700232
- GTIN : 00782634630104
- Dimensions : 4.63 in x 1.13 in x 1.13 in (Length/Depth x Height x Width)
- Weight : 1
