JDL36150SA - Square D PowerPact J 150A 3 Pole 600VAC Thermal Magnetic Circuit Breaker w/ Shunt Trip

JDL36150SA

JDL36150SA is a three-pole, 150A, 600VAC thermal magnetic molded case circuit breaker from the Square D PowerPact J series, featuring a shunt trip for remote operation. This circuit breaker is designed for reliable overcurrent protection and switching in commercial and industrial AC power systems. It features a 14kA interrupt rating, unit mount configuration, and is UL 489 listed for safety and compliance. The thermal magnetic trip unit provides both overload and short-circuit protection, while the shunt trip allows for remote tripping.

• Part Number: JDL36150SA
• Manufacturer: Square D / Schneider Electric
• Series/Frame: PowerPact J
• Amperage: 150A
• Voltage: 600VAC, 250VDC
• Poles: 3
• Interrupt Rating: 14kA @ 600VAC
• Mounting Type: Unit Mount
• Trip Unit: Thermal Magnetic
• Shunt Trip: Yes (110-130V AC)
• Certifications: UL 489 Listed, CSA Approved
• Dimensions: 4.09" W x 3.4" D x 7.5" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 110/120Vac shunt trip

Specifications

• Part Number: JDL36150SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JDL
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901630630
• GTIN : 00785901630630
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 4...AWG 4/0 aluminium/copper terminal
