JDL250 - Edison Fuses Class J Dual-Element Time-Delay Fuse, 250A, 600V, 200kA Interrupt Rating, Non-Indicating, Knife Blade, UL/CSA Certified

JDL250

JDL250 is a Class J, dual-element, time-delay, current-limiting fuse from Edison Fuses, designed for feeder and branch circuit protection in demanding electrical applications.

This non-indicating, knife blade fuse offers a 250A amperage rating and 600V voltage rating, with a high 200,000A interrupting capacity. Its compact size and robust construction make it ideal for protecting motors, transformers, and other equipment where reliable, time-delayed overcurrent protection is critical. The JDL series is known for its current-limiting performance and compliance with major safety standards.

Key Specifications
• Part Number: JDL250
• Manufacturer: Edison Fuses
• Category: Fuse
• Amperage: 250A
• Voltage: 600V AC
• Poles: 1
• Mounting Type: Knife Blade
• Interrupt Rating: 200,000A (200kAIC)
• Series/Frame: JDL
• Trip Unit: Dual-Element, Time-Delay (10 seconds minimum at 500% rated current)
• Certifications: UL, CSA C22.2
• Non-Indicating

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDL250
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Type : JDL
• Voltage : 600
• Amperage : 250
• AIC rating : 200kA@600V
• Connection : Bolt-In
• Diameter : 2.11
• Class Rating : J
• Barrels : 1

Product Data

• UPC : 78263480356
• GTIN : 00782634803560
• Dimensions : 7.13 in x 2.13 in x 2.13 in (Length/Depth x Height x Width)
• Weight : 1.7
