JDL1.6 - Edison Fuses 1.6 Amp 600 Volt Dual-Element Time-Delay Class J Fuse

JDL1.6

JDL1.6 is a 1.6 amp, 600 volt, dual-element time-delay Class J fuse from Edison Fuses designed for reliable circuit protection.This fuse features a true dual-element design providing a minimum 10 second time-delay at 500% overload, minimizing nuisance openings from temporary overloads and transient surges. It has a high interrupting rating of 200,000 amps RMS symmetrical at 600Vac, suitable for protecting circuits and motor starters. The fuse is non-indicating and complies with UL 248-8, CSA C22.2 No. 248.8, CE, cULus, and RoHS standards.

Key Specifications
• Amperage: 1.6 A
• Voltage Rating: 600 Vac
• Fuse Type: Class J
• Fuse Response: Time-Delay (Dual-Element)
• Interrupting Rating: 200kA RMS Symmetrical
• Mounting Type: Ferrule
• Certifications: UL, CSA, CE, cULus, RoHS
• Non-indicating
• Standard frame size
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: JDL1.6
• Manufacturer : Edison Fuses
• Brand : Edison Fuses



Product Data

• UPC : 78263463001
• GTIN : 00782634630012
• Dimensions : 2.25 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 1
