JD3125W - Eaton 125A 600V 3-Pole J-Frame Series C Molded Case Circuit Breaker Fixed Thermal Magnetic Trip

JD3125W

JD3125W is a complete molded case circuit breaker from Eaton's Series C, designed for reliable circuit protection.This Eaton JD3125W breaker features a 125 ampere rating, 600 VAC and 250 VDC voltage rating, and a three-pole configuration. It uses a fixed thermal and fixed magnetic trip unit for dependable interruption. The breaker is built on the J-frame and is rated for 65 kA interrupting capacity at 240 VAC and 35 kA at 480 VAC. It operates at 50/60 Hz frequency and comes without terminals.

Key Specifications
• Amperage: 125 A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: Three-pole
• Frame Type: J-frame
• Series: Series C
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 65 kAIC at 240 VAC, 35 kAIC at 480 VAC
• Frequency: 50/60 Hz
• Terminals: Without terminals
• Certifications: UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.




Specifications

• Part Number: JD3125W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : JD
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 782116093991
• GTIN : 00782116093991
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 9.55
• Certification : UL Listed
