Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage
Description
JCY-300E/325X
JCY-300E/325X is a medium voltage E-rated fuse designed for transformer and feeder protection with a 300/325 amp rating and 2750 volts. This double barrel fuse provides reliable current-limiting performance for indoor or enclosure applications.JCY-300E/325X features a filament wound glass epoxy fuse tube construction with plated ferrules, offering UV and moisture protection suitable for both indoor and outdoor use. It meets ANSI C37.46 and ANSI C37.40 standards for E-rated fuses, ensuring defined current response times and full range protection. The fuse has an interrupting rating of 80,000 amps symmetrical and 50,000 amps asymmetrical, with a length of 10.81 inches (276.35 mm) and diameter of 3 inches (76.2 mm). It includes an open fuse indicator for ease of troubleshooting.
- Key Specifications
- Amperage: 300/325 A
- Voltage Rating: 2750 V
- Poles: Double barrel
- Interrupting Rating: 80,000 A symmetrical, 50,000 A asymmetrical
- Construction: Filament wound glass epoxy tube with plated ferrules
- Standards: ANSI C37.46, ANSI C37.40
- Length: 10.81 in (276.35 mm)
- Diameter: 3 in (76.2 mm)
- Open fuse indicator included
Specifications
- Part Number: JCY-300E/325X
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage
- Type : JCY
- Voltage : 5500
- Amperage : 300
- Connection : Ferrule
- Barrels : 2
- Clip Center : 12
Product Data
- Weight : 5.19
