Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
JCL-A-24R
JCL-A-24R is a medium voltage R-rated fuse designed for motor circuit protection by Eaton.This fuse features a 450 ampere rating and is suitable for use at voltages up to 2.4 kV nominal (maximum design voltage 2.54 kV). It is constructed as a single-barrel fuse link with a 76 x 400 mm dimension and is UL Recognized. The JCL-A-24R fuse has an interrupting rating of 50 kA symmetrical and 80 kA asymmetrical, ensuring reliable protection for medium voltage applications.
- Key Specifications
- Amperage: 450 A
- Voltage: 2.4 kV nominal, 2.54 kV max design
- Fuse Type: R-Rated Medium Voltage Fuse
- Dimensions: 76 x 400 mm
- Interrupt Rating: 50 kA Symmetrical, 80 kA Asymmetrical
- Mounting: Single barrel fuse link
- UL Recognized
- Part Number: JCL-A-24R
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : JC Series
- Type : JCL
- Voltage : 5080
- Amperage : 450
- AIC rating : 50kA@4800V
- Diameter : 3
- Class Rating : R
- Barrels : 2
- UPC : 05171269138
- GTIN : 00051712691383
- Weight : 19
