Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
JCK-A-5R
JCK-A-5R is a 150 Amp R-Rated fuse designed by Eaton for medium voltage motor circuit protection applications.
This cartridge fuse is rated for 2.4 kV AC and provides reliable short-circuit protection for motor circuits. It is part of Eaton's Bussmann series and meets ANSI C37.46 standards for R-Rated fuses, melting within 15 to 35 seconds at 100 times the rated current. The fuse is UL Recognized and suitable for use in existing hardware due to its physical dimensions.
- Key Specifications
- Amperage: 150 Amps
- Voltage Rating: 2.4 kV AC
- Fuse Type: Cartridge
- R-Rated for motor circuit protection
- Interrupting Rating: 50 kA Symmetrical
- Standards: ANSI C37.46, UL Recognized
- Mounting Type: Designed for easy installation in existing hardware
- Series: Bussmann
- Part Number: JCK-A-5R
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : JC Series
- Type : JCK
- Voltage : 2540
- Amperage : 150
- AIC rating : 50kA@2400V
- Diameter : 3
- Class Rating : R
- Barrels : 1
- UPC : 05171217360
- GTIN : 00051712173605
- Weight : 7
