Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
JCK-A-3R
JCK-A-3R is a 100 amp, 2.4 kV R-rated medium voltage fuse designed for motor circuit protection by Eaton.JCK-A-3R features a 50 kA symmetrical interrupting rating and is part of Eaton's AMPGARD series, suitable for use in 400 amp motor starters. It is a single-pole fuse with a bolt-on mounting type and UL Recognized certification, providing reliable current limiting protection for medium voltage applications.
- Amperage: 100 A
- Voltage Rating: 2.4 kV nominal, 2.54 kV max design
- Interrupting Rating: 50 kA symmetrical
- Fuse Class: R-Rated
- Poles: 1
- Mounting Type: Bolt-on
- Series/Frame: AMPGARD
- UL Recognized: Guide MSSS2, File E96676
- Diameter: Approximately 3 inches
- Application: Motor circuit protection
Specifications
- Part Number: JCK-A-3R
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : JC Series
- Type : JCK
- Voltage : 2540
- Amperage : 100
- AIC rating : 50kA@2400V
- Diameter : 3
- Class Rating : R
- Barrels : 1
Product Data
- UPC : 05171214442
- GTIN : 00051712144421
- Weight : 7
