Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
JCK-3R
JCK-3R is a 100-amp R-rated current-limiting cartridge fuse designed for motor circuit protection in medium voltage applications. This Eaton Bussmann Series fuse provides reliable overcurrent protection with fast response characteristics and is suitable for use in existing motor control hardware. Key Specifications
- Part Number: JCK-3R
- Manufacturer: Eaton Bussmann Electrical Division
- Current Rating: 100 Amps
- Voltage Rating: 2.4 kVAC nominal, 2.54 kVAC maximum design
- Fuse Type: Cartridge, Current-Limiting
- Class: R-Rated
- Interrupting Rating: 50 kA RMS Symmetrical, 80 kA Asymmetrical
- Response Time: Melts in 15 to 35 seconds at 100 times the R-number per ANSI C37.46
- Agency Certification: UL Recognized, Guide MSSS2, File E96676
- Standards Compliance: ANSI C37.46
Specifications
- Part Number: JCK-3R
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : JC Series
- Type : JCK
- Voltage : 2540
- Amperage : 100
- AIC rating : 50kA@2400V
- Diameter : 3
- Class Rating : R
- Barrels : 1
Product Data
- UPC : 05171269003
- GTIN : 00051712690034
- Country of Origin : Mexico
- Weight : 6
