Product Info
- Manufacturer:Bussmann
- Sub-Category:Fuse Block
Description
J60100-1CR
J60100-1CR is a Class J fuse block rated for 100 amperes at 600 volts AC with 1-pole configuration and box lug terminals suitable for copper or aluminum conductors. This thermoplastic fuse block is designed to accept Bussmann LPJ and JKS Class J fuses and features spring-reinforced construction with a retaining clip for secure fuse retention. The unit is panel-mountable and compatible with conductor sizes from 2/0 to #6 AWG.
- Amperage Rating: 100A
- Voltage Rating: 600V AC
- Poles: 1-Pole
- Fuse Class: UL Class J
- Connection Type: Box Lug
- Conductor Range: 2/0 to #6 AWG (Copper or Aluminum)
- Enclosure Material: Thermoplastic
- Interrupt Rating: 200 kAIC
- Mounting: Panel Mount
- Features: Spring Reinforced, Retaining Clip
Specifications
- Part Number: J60100-1CR
- Manufacturer : Bussmann
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Fuse Block
- Voltage : 600
- Amperage : 100
- Mounting : Box
Product Data
- UPC : 051712617024
- Weight : 1
- Certification : CE
