J250DS - Square D PowerPact H/J Circuit Breaker Enclosure 250A 600V 2/3 Pole Stainless Steel NEMA 3/3R/4/4X/5

J250DS

J250DS is a Square D PowerPact H and J frame circuit breaker enclosure designed for 2 and 3 pole breakers with 15 to 250 amp ratings.This enclosure supports circuit breakers up to 600 volts AC, is constructed from stainless steel, and features a NEMA 3/3R/4/4X/5 rating for versatile indoor/outdoor use. It measures 32.26 inches high by 9.72 inches wide by 7.94 inches deep and mounts on the surface. The enclosure is UL 489 listed and CSA certified, suitable for service entrance equipment, and accepts 100% rated breakers. It includes side-hinged cover with latch closure and conduit provisions for multiple sizes.

Key Specifications
• Amperage: 15-250 A
• Voltage: 600 V AC
• Poles: 2 or 3
• Mounting Type: Surface mount
• Material: Stainless steel
• NEMA Rating: 3, 3R, 4, 4X, 5
• Dimensions: 32.26" H x 9.72" W x 7.94" D
• Certifications: UL 489, CSA, IEC
• Frame: PowerPact H and J
• Cover: Side hinge with latch
• Conduit Provisions: Multiple sizes
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

Please note that circuit breakers are not included with the enclosures and must be purchased separately.




Specifications

• Part Number: J250DS
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Enclosure
• Family : Powerpact
• Type : J
• Voltage : 600
• Amperage : 250
• Temp Rating : -13–158 °F (-25–70 °C)
• Compatible Frames : HDL,HGL,HJL,HLL,JDL,JGL,JJL,JLL



Product Data

• UPC : 785901507598
• GTIN : 00785901507598
• Country of Origin : Mexico
• Dimensions : 32.26 in (819.40 mm) x 9.72 in (246.89 mm) x 7.94 in (201.68 mm) (Height x Width x Depth)
• Weight : 25.84
