IBPFD3070 - Eaton 70A 600V Three-Pole Pow-R-Way FD Frame Circuit Breaker Plug-In Unit

IBPFD3070

IBPFD3070 is a 70 Amp, 600 Volt, three-pole Pow-R-Way FD frame circuit breaker plug-in unit designed for busway applications.IBPFD3070 features an FD type breaker with an F frame rating, providing reliable protection and plug-in convenience for busway systems. It supports 65 kAIC interrupt rating at 240 Vac, 25 kAIC at 480 Vac, and 18 kAIC at 600 Vac, ensuring high fault current interruption capability. The unit is NEMA compliant and certified to ANSI, IEEE, UL 857, and CSA standards, with grounding options including 50% integral or housing ground.

Key Specifications
• Amperage: 70 Amp
• Voltage: 600 Volt
• Poles: Three-pole
• Frame: F Frame (15-225 A range)
• Design: Pow-R-Way III
• Circuit Breaker Type: FD
• Interrupt Rating: 65 kAIC at 240 Vac, 25 kAIC at 480 Vac, 18 kAIC at 600 Vac
• Application: Busway
• Certifications: ANSI, IEEE, UL 857, CSA
• Grounding: 50% Integral or Housing Ground
• Compliance: NEMA Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: IBPFD3070
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Bus Plug
• Item Subcategory : Breaker Type
• Family : POW-R-WAY I And II
• Type : IBPFD
• Voltage : 600
• Amperage : 70
• Phase : 3
• AIC rating : 35kA@480V
• Wire : 3
• Compatible Frames : FD

Product Data

• UPC : 786683018159
• GTIN : 00786683018159
• Country of Origin : United States
• Dimensions : 20.91 in x 5.06 in x 11.07 in (Length/Depth x Height x Width)
• Weight : 17
• Certification : CSA Certified,IEEE Certified,UL 857,ANSI,NEMA Compliant
