Product Info
- Manufacturer:Siemens
Description
HT23
HT23-601C is a high torque NEMA 23 two-phase stepper motor designed for DC powered drives and motion control applications.This stepper motor features a 1.8 degree step angle, bipolar series current of 2.12 A per phase, and a 10-foot shielded cable for flexible installation. It delivers a bipolar holding torque of 269 oz-in and unipolar holding torque of 191 oz-in, making it suitable for precise and powerful motion control. The motor has 8 lead wires with a 22 AWG gauge and a rotor inertia of 6.51E-03 oz-in-sec.
- Frame Size: NEMA 23
- Motor Type: High Torque 2-Phase Stepper
- Step Angle: 1.8 degrees
- Bipolar Series Current: 2.12 A/phase
- Bipolar Holding Torque: 269 oz-in
- Unipolar Holding Torque: 191 oz-in
- Lead Wire Length: 10 feet shielded cable
- Lead Wire Gauge: 22 AWG
- Number of Lead Wires: 8
- Rotor Inertia: 6.51E-03 oz-in-sec
Specifications
- Part Number: HT23
- Manufacturer : Siemens
- Brand : Siemens
Product Data
- UPC : 078364317347
- GTIN : 00783643173477
- Weight : 5.19
