HRL36150M74 - Schneider Electric PowerPact H Frame 150 Amp 3 Pole 600 VAC Motor Circuit Protector

HRL36150M74

HRL36150M74 is a Schneider Electric PowerPact H Frame motor circuit protector designed for reliable motor protection in industrial applications.This molded case circuit breaker features a 150 amp rating, 3 poles, and a 600 VAC voltage capacity. It has a thermal magnetic trip unit and an interrupt rating of 100kA, suitable for heavy-duty motor circuit protection. The breaker is UL 489 listed and meets multiple certifications including CSA, NEMA, IEC, and CE. It is a unit mount type compatible with PowerPact H frame accessories.

Key Specifications
• Amperage: 150 Amp
• Voltage: 600 VAC
• Poles: 3
• Mounting Type: Unit Mount
• Interrupt Rating: 100kA
• Series/Frame: PowerPact H Frame
• Trip Unit: Thermal Magnetic
• Certifications: UL 489, CSA, NEMA, IEC, CE
• Motor Circuit Protector
• 80% Rated for continuous operation
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HRL36150M74
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HRL
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 200kA@480V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Magnetic Only



Product Data

• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
