HRL36100M73 - Schneider Electric PowerPacT H Motor Circuit Protector 100A 3 Pole 600V 100kA Thermal Magnetic

HRL36100M73

HRL36100M73 is a Schneider Electric PowerPacT H motor circuit protector rated for 100 amps, 3 poles, and 600 volts with a 100kA interrupt rating.HRL36100M73 features thermal magnetic trip technology, unit mount lug connections on both line and load sides, and an 80% continuous current rating. It is UL 489 listed and certified to CSA, NEMA, NMX, VDE, BS, CCC, IEC standards, and CE marked for global acceptance.

Key Specifications
• Amperage: 100A
• Voltage Rating: 600 VAC
• Poles: 3
• Interrupt Rating: 100kA at 600 VAC
• Frame/Series: PowerPacT H
• Trip Unit: Thermal Magnetic
• Mounting Type: Unit mount lug
• Continuous Current Rating: 80%
• Connection: Lugs on line and load sides
• Certifications: UL 489, CSA, NEMA, NMX, VDE, BS, CCC, IEC, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HRL36100M73
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HRL
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 200kA@480V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Magnetic Only

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
