Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
HQR22B100L
HQR22B100L is a Siemens 2 pole, 100 amp, 240 volt molded case circuit breaker from the QR series frame designed for bolt-on mounting.This circuit breaker features a 65kA interrupt rating at 240VAC, thermal magnetic trip unit, and line/load side lugs compatible with wire sizes from 6 AWG to 1/0 AWG. It is suitable for standard 40°C applications and provides reliable overcurrent protection in residential, commercial, and light industrial electrical systems.
- Manufacturer: Siemens
- Part Number: HQR22B100L
- Amperage: 100 Amps
- Voltage: 240 VAC
- Poles: 2
- Frame/Series: QR Frame (HQR)
- Mounting Type: Bolt-On
- Interrupt Rating: 65,000 Amps (65kA)
- Trip Unit: Thermal Magnetic
- Wire Range: 6 AWG to 1/0 AWG
- Certifications: UL Listed, CSA Certified
Specifications
- Part Number: HQR22B100L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QR Series
- Type : HQR2
- Voltage : 240
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 65kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 804766136399
- GTIN : 00804766136399
- Country of Origin : Mexico
- Dimensions : 7.087 x 4.331 x 3.937 inch
- Weight : 3.197
