HOMT3015 - Square D Homeline Tandem Circuit Breaker, 1 Pole, 30A & 15A, 120/240V, Plug-In Mount, 10kA Interrupt, UL Listed

HOMT3015

HOMT3015 is a Square D Homeline tandem circuit breaker designed for efficient protection of two circuits in a single slot.

This plug-in mount breaker features independent trip switches for each circuit, with one pole rated at 30A and the other at 15A, operating at 120/240V AC. It is UL listed and offers a 10kA interrupt rating for reliable safety in residential and light commercial applications. The breaker is compatible with copper and aluminum wiring and meets California Proposition 65 standards.

Key Specifications

• Manufacturer: Square D
• Series/Frame: Homeline
• Part Number: HOMT3015
• Amperage: 30A & 15A (tandem)
• Voltage: 120/240V AC
• Poles: 1 (tandem design occupies one space, protects two circuits)
• Mounting Type: Plug-in
• Interrupt Rating: 10 kA
• Trip Unit: Independent thermal-magnetic for each circuit
• Certifications: UL Listed
• Wiring: Accepts copper and aluminum
• Standards: Meets California Proposition 65

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HOMT3015
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : HOMELINE
• Type : HOMT
• Voltage : 120
• Amperage : 30
• Poles : 1
• AIC rating : 10kA@120V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Box Lugs
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 8 AWG (Cu/Al)
• Breaker Type : Tandem
• Protection : Thermal Magnetic

Product Data

• UPC : 785901141945
• GTIN : 00785901141945
• Country of Origin : Mexico
• Dimensions : 3.13 in (79.50 mm) x 1 in (25.4 mm) x 2.98 in (75.69 mm) (Height x Width x Depth)
• Weight : 0.45
• Standards : UL Listed
• Certification : UL Listed
