HNF366SA - Siemens 600A 600V 3-Pole NEMA 4X Heavy Duty Non-Fused Safety Switch

HNF366SA

This Siemens HNF366SA switch features a 3-pole, 3-wire configuration rated for 600 VAC and 600 Amps. It is housed in a Type 4/4X 304 grade stainless steel enclosure, providing excellent corrosion resistance and durability. The switch is non-fusible and has an interrupt rating of 200kA at 600V. It complies with UL 98 standards and supports horsepower ratings up to 50 hp at 600V. This model is part of the VBII series, suitable for heavy duty industrial and commercial power distribution needs.

Key Specifications
• Amperage: 600 A
• Voltage: 600 V AC
• Poles: 3
• Mounting Type: Surface mount
• Interrupt Rating: 200kA at 600V
• Enclosure Type: NEMA 4/4X stainless steel
• Series/Frame: VBII
• Trip Unit: Non-fused
• Certifications: UL 98
• Horsepower Rating: 50 hp at 600V

At Essential Parts, we offer fast shipping, lo(more...)


Specifications

• Part Number: HNF366SA
• Manufacturer : Siemens
• Brand : Siemens
• Category : Switch
• Item Subcategory : Disconnect
• Section : Non-Fusible Disconnect Switch
• Family : VBII Series
• Type : HNF
• Voltage : 600 AC AC
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 200kA@600V
• Configuration : Single
• Switch Style : Non-Fusible
• Nema Rating : NEMA 4X
• Switch Type : Non-Fusible



Product Data

• UPC : 887621872748
• GTIN : 0887621872748
• Country of Origin : Mexico
• Dimensions : 7.087 x 22.047 x 33.465 inch
• Weight : 4.7 lb
• Certification : UL listed
