HMCPS050K2C - Cutler Hammer 50A 600VAC 3 Pole Molded Case Circuit Breaker, Series C, Frame J-K, Motor Circuit Protector, Thermal Magnetic Trip

HMCPS050K2C

HMCPS050K2C is a Cutler Hammer 3-pole molded case circuit breaker designed for motor circuit protection and general electrical distribution applications.

This thermal magnetic circuit breaker features a 50A current rating, 600VAC/250VDC voltage rating, and is part of the C Series with Frame J-K. It is suitable for use with electric starters, offers adjustable trip settings, and is engineered for reliable performance in demanding environments. The non-aluminum terminals ensure secure connections and long service life.

Key Specifications
• Part Number: HMCPS050K2C
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 50A
• Voltage: 600VAC, 250VDC
• Poles: 3
• Mounting Type: Panel or enclosure (NEMA 2 starter compatible)
• Interrupt Rating: Not specified in available data
• Series/Frame: C Series, Frame J-K (50-500A)
• Trip Unit: Thermal magnetic, adjustable (A to H cam setting)
• Certifications: Not specified in available data
• Connection: Feed-thru
• Phase: 3

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HMCPS050K2C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCPS
• Voltage : 600
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/J
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Magnetic Only
• Phase Connection : ABC

Product Data

• UPC : 786679232644
• GTIN : 00786679232644
• Country of Origin : Dominican Republic
• Dimensions : 8 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Motor Starters Equipped with Electronic Overload Relays
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
