HMCPE050K2C - Cutler Hammer 50A 480V 3-Pole Motor Circuit Protector Circuit Breaker Frame J-K

HMCPE050K2C

HMCPE050K2C is a Cutler Hammer 50 amp, 480 volt, 3-pole motor circuit protector circuit breaker with Frame J-K and feed-thru mounting.This motor circuit protector features a non-interchangeable trip unit with instantaneous magnetic trip protection adjustable from 50 to 500 amps. It is designed for 3-phase motor protection with a 15kA interrupt rating at 400V and is UL Listed and CSA Certified. The breaker has non-aluminum line and load side lug terminals and a NEMA 2 rating.

• Amperage: 50 A
• Voltage: 480 V
• Poles: 3
• Frame Size: J-K
• Trip Type: Non-interchangeable instantaneous magnetic trip
• Magnetic Trip Range: 50-500 A
• Interrupt Rating: 15kA @ 400 V
• Mounting Type: Feed-Thru
• Terminal Material: Non-aluminum
• Phase: 3
• Certifications: UL Listed, CSA Certified
• NEMA Rating: NEMA 2

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HMCPE050K2C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : HMCPE
• Voltage : 480
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 15kA@400V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Protection : Magnetic Only

Product Data

• UPC : 786679113677
• GTIN : 00786679113677
• Country of Origin : Dominican Republic
• Dimensions : 6.5 in x 4.5 in x 4 in (Length/Depth x Height x Width)
• Weight : 2.6
• Certification : CSA Certified, IEC Rated, UL Listed
