Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
HMCP400F5
HMCP400F5 is a 3 pole, 400 amp, 600 volt molded case circuit breaker from Westinghouse designed for reliable motor circuit protection.This HMCP400F5 circuit breaker features a K-frame style with a 35kA interrupting rating at 480V, suitable for industrial and commercial electrical distribution. It provides robust protection with a magnetic non-interchangeable trip unit and bolt-on mounting type, ensuring secure and stable installation. The breaker is UL listed and designed to meet rigorous safety and performance standards.
- Amperage: 400A
- Voltage Rating: 600V
- Poles: 3
- Interrupting Rating: 35kA at 480V
- Frame/Series: K-Frame
- Trip Unit: Magnetic Non-Interchangeable
- Mounting Type: Bolt-on
- UL Listed
- Manufacturer: Westinghouse
Specifications
- Part Number: HMCP400F5
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HMCP
- Voltage : 600
- Amperage : 400
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : Instantaneous Trip
- Frame Size : K Frame
- Protection : Magnetic Only
Product Data
- UPC : 786679342329
- GTIN : 00786679342329
- Country of Origin : Dominican Republic
- Dimensions : 4.1 in x 10.13 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 11.5
- Certification : UL Listed,CSA Certified
