Product Info
- Manufacturer:Cutler Hammer
Description
HMCP150U4CH09
HMCP150U4CH09 is a Cutler Hammer 150A 3-pole molded case circuit breaker designed for reliable motor circuit protection in industrial applications. This Series C circuit breaker features a magnetic trip unit, F frame, and is rated for 600V AC and 250V DC. It is suitable for feed-thru mounting and provides robust protection for motor loads with a trip setting range of 750 to 2500 amps. The breaker is UL Listed and CSA Certified for safety and compliance.
- Part Number: HMCP150U4CH09
- Manufacturer: Cutler Hammer
- Amperage: 150A
- Voltage Rating: 600V AC, 250V DC
- Poles: 3
- Mounting Type: Feed-Thru
- Interrupt Rating: 750-2500A
- Series/Frame: Series C, F Frame
- Tripping Type: Magnetic Only
- Certifications: UL Listed, CSA Certified
- Application: Motor Circuit Protection
- Terminal Material: Non-Aluminum
Specifications
- Part Number: HMCP150U4CH09
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
Product Data
- UPC : 78667904262
- GTIN : 00786679042625
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
