Product Info
- Manufacturer:Cutler Hammer
Description
HMCP150T4CH09
HMCP150T4CH09 is a 150 amp, 600 volt, 3-pole motor circuit protector from Cutler Hammer designed for reliable motor protection.This Series C, Frame J-K motor circuit protector features line and load terminals, a magnetic trip range of 450-1500 amps, and is UL Listed and CSA Certified. It supports 600 VAC and 250 VDC ratings with non-aluminum terminals and panel mounting.
- Amperage: 150 A
- Voltage Rating: 600 VAC, 250 VDC
- Poles: 3
- Frame: J-K
- Series: C
- Trip Unit: Magnetic trip range 450-1500 A
- Mounting Type: Panel mount
- Terminal Material: Non-aluminum
- Certifications: UL Listed, CSA Certified
- Line and load terminals
- Motor circuit protector type
Specifications
- Part Number: HMCP150T4CH09
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
Product Data
- UPC : 78667901443
- GTIN : 00786679014431
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
