HMCP100R3W - Eaton 100A 600V 3-Pole Motor Circuit Protector Frame J-K Series C

HMCP100R3W

HMCP100R3W is a 3-pole motor circuit protector by Eaton designed for reliable motor protection in industrial applications.

This molded case circuit breaker features a 100 ampere rating, 600 volts AC voltage rating, and is built on Eaton's Frame J-K, Series C platform. It provides motor circuit protection with a magnetic trip range of 300-1000 A, ensuring precise and effective overload and short circuit protection. The device is UL Listed and CSA Certified, confirming compliance with industry safety standards. It is supplied without terminals and is suitable for use in three-phase motor circuits.

• Amperage: 100 A
• Voltage: 600 V AC
• Poles: 3
• Frame Size: J-K
• Series: C
• Type: Motor Circuit Protector
• Magnetic Trip Range: 300-1000 A
• Certifications: UL Listed, CSA Certified
• Mounting: Molded Case

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HMCP100R3W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCP
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : I - Instantaneous
• Frame Size : F Frame
• Protection : Magnetic Only

Product Data

• UPC : 782114209707
• GTIN : 00782114209707
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed,CSA Certified
