HMCP100R3CA01 - Eaton 100A 3-Pole Motor Circuit Protector Frame J-K Series C

HMCP100R3CA01

HMCP100R3CA01 is a 100 amp, three-pole motor circuit protector from Eaton designed for reliable motor protection.This molded case circuit breaker accessory features a Frame J-K, Series C design with a magnetic trip range of 300-1000 A. It supports line and load lug connections, is rated for 600 VAC and 250 VDC, and includes a 1A-1B auxiliary switch with left pigtail on the same side. The unit is UL Listed and CSA Certified, suitable for panel mounting with NEMA 3 enclosure type.

Key Specifications
• Amperage: 100 A
• Poles: Three-pole
• Frame: J-K
• Series: Series C
• Voltage Rating: 600 VAC, 250 VDC
• Mounting Type: Panel mount
• Connection Type: Line/Load Lug
• Auxiliary Switch: 1A-1B Left pigtail same side
• Interrupt Rating: 300-1000 A magnetic trip range
• Enclosure Type: NEMA 3
• Certifications: UL Listed, CSA Certified
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HMCP100R3CA01
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case



Product Data

• UPC : 786679039502
• GTIN : 00786679000000
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : CSA Certified,UL Listed
