Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HMCP070M2W
HMCP070M2W is an Eaton molded case circuit breaker motor circuit protector designed for three-phase motor protection applications. This Series C motor protection device features a 70 ampere rating with instantaneous magnetic trip protection and feed-thru connection configuration for panel mounting. Key Specifications
- Amperage Rating: 70A
- Voltage: 480 VAC
- Number of Poles: 3-Pole
- Frame Size: J-K
- Series: Series C
- Connection Type: Feed-Thru
- Trip Function: Instantaneous Magnetic
- Mounting: Panel
- Certifications: UL Listed, CSA Certified, CE
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: HMCP070M2W
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HMCP
- Voltage : 600
- Amperage : 70
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : I - Instantaneous
- Frame Size : F Frame
- Protection : Magnetic Only
Product Data
- Weight : 5
