HM2P250L5W - Cutler-Hammer Eaton Westinghouse Series C 250A 2P Motor Circuit Protector, Frame J-K, 600VAC/250VDC, Magnetic Trip

HM2P250L5W

HM2P250L5W is a Cutler-Hammer, Eaton, and Westinghouse Series C motor circuit protector designed for reliable motor circuit protection in industrial applications.

This two-pole motor circuit protector features a 250A amperage rating, 600V AC and 250V DC voltage rating, and is built on a Frame J-K platform. It utilizes a magnetic trip mechanism with a trip range of 1125–2250A, providing robust short-circuit protection without thermal overload functionality. The unit is supplied without terminals and is suitable for panel or enclosure mounting.

Key Specifications
• Part Number: HM2P250L5W
• Manufacturer: Cutler-Hammer, Eaton, Westinghouse
• Amperage: 250A
• Voltage: 600V AC, 250V DC
• Poles: 2
• Mounting Type: Panel/Enclosure (no terminals included)
• Interrupt Rating: Not specified in available data
• Series/Frame: Series C, Frame J-K
• Trip Unit: Magnetic only (1125–2250A)
• Certifications: Not specified in available data

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HM2P250L5W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HM2P
• Voltage : 600
• Amperage : 250
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : I - Instantaneous
• Protection : Magnetic Only

Product Data

• UPC : 786679160404
• GTIN : 00786679160404
• Country of Origin : Dominican Republic
• Dimensions : 1 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 0.1
• Certification : CSA Certified,UL Listed
